Nantong Technology 500
Workbench division 1 °× 360
Maximum speed of turntable r/min5
Fast moving speed m/min24
Cutting feed rate mm/min 3-15000
Spindle taper hole -7:24 No.40
Maximum spindle speed rpm8000
Knife magazine type - robotic arm
Knife storage capacity (pcs) 30
Tool change time (seconds) sec3
Maximum tool diameter mm * 77
Adjacent maximum tool diameter without a blade, mm * 130
Maximum tool length mm320
Maximum single blade weight kg8
Axis positioning accuracy (JB/T8771.4) mm0.010
Repositioning accuracy (JB/T8771.4) mm0.006
Spindle motor power kw9/11
X、Y、Z、 4-axis motor torque Nm12/30/22/8
Machine tool dimensions (length x width x height) mm 4050 x 2900 x 2940
Net weight of machine tool kg12000
Electricity demand KVA47
